Straight Running Belts

Straight Running Conveyor belts are crucial for the success of any manufacturer, processor, or distributor. When they work as they should, you might not even notice them. However, if even one belt fails to function properly, it can lead to difficulties throughout the entire production line and potentially affect your entire plant.
Straight Running Belts

Straight Running

Discover our wide variety of belts available with varying pitches, openings, surface types, accessories, materials and colours.

  • Advanced polymers improve non-stick characteristics, reduce friction and lower power consumption
  • Metal detectable, flame-retardant, electrical conductive, high temperature resistant
  • Safe conveying for food & non-food items (such as cartons, cans, cars, trucks and even humans!)

uni NTB

The Nano Transfer Belt. Size matters! The smallest pitch modular belt in our product range. Great for conveying small bakery products and/or delicate goods smoothly.
Product features:
  • Ideal for tight transfers
  • Designed for use with knife-edge transfers
  • Hinge remains closed around knife-edge
  • Clever sprocket design provides tracking
  • Closed surface for food applications
uni NTB Closed

Universal small pitch belt for food and industrial applications.

Product features:

  • Rounded bottom surface ensures smooth running over knife-edge transfers
  • Closed top surface and hinges
  • High load capacity
  • Unique lock-pin locking system for easy maintenance
uni M QNB Closed

Open area, cleanable small pitch belt. A perfect solution for food processing (cooling, freezing, drying or proofing applications).

Product features:

  • High strength robust design
  • Smooth operation over small transfers
  • Improved non-stick characteristics and reduced friction with standard POM-D and PP materials.
  • Efficient product transfer and less product contact area with the curved surface design
uni M TTB Curved Surface 37 Open

Ideal for transporting and processing applications needing small in-line transfers. Good option to replace old (and often dirty) steel wire mesh belts.

Product features:

  • Very open design
  • Low contact surface area
  • Smooth running over transfers
uni M OWL corner

Open area 0.5 inch pitch belt system suitable for food and non-food applications needing small transfer gaps.

Product features:

  • Small pitch with open surfaces
  • Knife-edge transfers possible
  • Choice of surface profiles
uni M QNB Closed

Modular belt for container handling. Metric width standards.

Product features:

  • 8.7 mm thickness
  • Profiled belt base for smooth in-line product transfers over knife end profiles
  • Active sideways Transfer system and tracking guides
9123

uni Light

Universal small pitch belt for industrial and packaged products transportation.

Product features:

  • Open and closed surfaces
  • Closed hinge construction
  • Versatile belt available in many variations
  • Full range of accessories
uni Light Closed

A best seller!

Open 1 inch pitch belt with a very cleanable design for a variety of applications mainly in food and beverage.

Product features:

  • High strength and easy to use LockPin system
  • Reduced dirt build up thanks to different self-cleaning surfaces
  • Less friction and product contact
  • Available in a variety of open ratios
  • Customisable: rubbertop, tabs, flights
uni SNB M2 34

Strong hygienic 1 inch pitch belt suitable for raw food processing applications.

Is available in the unique uni Single Link® format.

Product features:

  • Easy to clean hygienic belt
  • Open hinge designed for pressure wash cleaning
  • Impact-resistance bar on underside
  • Available with unique 20 inch wide flight
uni S MPB Closed

Very easy to clean 1 inch pitch belt for conveyance of light duty products in various food applications.

Product features:

  • Unique hinge and sprocket designs increase the cleanability
  • Available with different openings to optimise drainage and airflow
uni S MPB Closed

Standard 1 inch pitch closed belt for reliable conveying in a multitude of industries.

Developed with focus on optimising strength, rigidity and wear life.

Product features:

  • Unique sprocket engagement reducing pulsation
  • Strong bi-directional belt for long conveyors
  • Chamfered edges provide easy side transfers
uni M QNB Closed

An industry favourite!

Standard belt for Corrugated Board Industry stack handling systems.

Product features:

  • Safewalk Y profile top surface
  • High visibility belt edges
  • Profiled base for smooth product transfers
  • High working load capacity
uni JCB Y

The revolution of uni ITB lies in its compatibility, offering seamless integration into your current setup, including the ability to run on the existing sprockets. It’s the ideal choice for swift repairs to previously installed similar belts, eliminating the need for conveyor design modifications. This belt ensures instant performance enhancements.



Product features:

  • 0.5″ Belt Thickness
  • 1.0″ Pitch
  • Superior Link Flatness
  • Solid Closed Hinge
  • Travel Direction
  • uni LockPin System
uni ITB pallet

Light duty 1 inch pitch people mover belt, ensuring that workers are transported at the same speed as the product being assembled.

Moving people safely with ‘gentle grip’ belt profile.

Features a safe walk surface, high tensile working load capacity and rigidity and is low friction and wear-resistant.

Product features:

  • High tensile load capacity
  • Long conveyors possible
  • Safe walk surface
  • Anti-static material options
uni LPB Rough

Modular belt for container handling. Metric width standards.

Product features:

  • 8.7 mm thickness
  • Flat smooth top surface for container stability
  • Active sideways Transfer system and tracking guides
uni Light Closed

uni OWL

Very open 1.1 inch pitch belt with a patented non-stick belt surface created for applications requiring large open areas and little product contact.

Product features:

  • Heat and wear-resistant
  • Operating temperature of 180 °C with special material
  • Can resist peak temperature up to 230 °C with special material
  • Minimal contact surface
uni OWL 66 Open

uni Light EP

1.5 inch pitch belt designed for light duty applications such as cooking, blanching and pasteurizing in the Food Industry.

Product features:

  • Comes with various openings including fine-mesh for water drainage and filtering
  • Steel reinforcement feature limits belt elongation (even in hot water)
  • Reinforced product supports for high load elevators
uni LightEP 28 Open

uni SSB

Developed for heavy duty applications such as accumulation tables and packaging application.

Product features:

  • Strong and wear-resistant belt
  • Closed and wide hinge design increasing product stability
  • Chamfered edges allowing stability in side transfer applications
uni SSB Closed

uni ACB

The next level in automotive belting – the Advanced Concept Belt.

Versatile 40mm pitch belt used for medium duty vehicle and people conveying solutions.

Product features:

  • High load capacity
  • Lower construction heights (less pit depth)
  • Patented dual compound technology
  • Increased wear-resistance
uni ACB rough corner

Early generation 50mm pitch belt, available in a variety of executions.

Designed for high performance with various food products, especially for cooking, blanching and pasteurizing.

Executions and product features:

  • Small or large opening including fine mesh for water drainage
  • Finger plates for easy product transfer
  • Pitch control with steel reinforcement feature
uni OPB 4V 23 Open Fine Meshed

Easy clean, very open 2 inch pitch belt for various industries.

Product features:

  • Less friction and product contact
  • Large open area for easy drainage
  • Small back flex radius for lower profile conveyors
uni L SNB 36 Open
